| Alles weergeven | |||
| Drill Ø, up to (mm) | 14 | ||
| Fulfils ece standard | ece-r90 | ||
| Centering diameter (mm) | 60 | ||
| Surface | coated | ||
| Min. thickness (mm) | 10 | ||
| Bolt hole circle Ø (mm) | 105 | ||
| Supplementary article/supplementary info 2 | with bolts/screws | ||
| Num. of holes | 5 | ||
| Brake disc thickness (mm) | 12 | ||
| Brake disc type | solid | ||
| Outer diameter (mm) | 288 | ||
| Height (mm) | 45 | ||
Incl. vat 5%
Incl. vat 5%
| Alles weergeven | |||
| Centering diameter (mm) | 60.0 | ||
| Appr. stamp | e1 90r-02c0165/1007 | ||
| Surface | coated | ||
| Min. thickness (mm) | 10.0 | ||
| Bolt hole circle Ø (mm) | 105.0 | ||
| Supplementary article/supplementary info 2 | with bolts/screws | ||
| Bore Ø (mm) | 14.0 | ||
| Num. of holes | 5 | ||
| Brake disc thickness (mm) | 12.0 | ||
| Brake disc type | solid | ||
| Inner diameter (mm) | 156.0 | ||
| Outer diameter (mm) | 288.0 | ||
| Height (mm) | 45.0 | ||
Incl. vat 5%
Incl. vat 5%
| Alles weergeven | |||
| Packaging height (cm) | 12.7 | ||
| Packaging width (cm) | 30.8 | ||
| Packaging length (cm) | 30.8 | ||
| Wheel bolt bore Ø (mm) | 14.1 | ||
| Hole pitch/number | 05/06 | ||
| Centering diameter (mm) | 60 | ||
| Weight (kg) | 5.2 | ||
| Surface | coated | ||
| Min. thickness (mm) | 10 | ||
| Bolt hole circle Ø (mm) | 105 | ||
| Supplementary article/supplementary info 2 |
|
||
| Brake disc thickness (mm) | 12 | ||
| Brake disc type | solid | ||
| Inner diameter (mm) | 156 | ||
| Outer diameter (mm) | 288 | ||
| Height (mm) | 45.3 | ||
| Weight | 5.48 kg | ||
Incl. vat 5%
Incl. vat 5%
